| Numéro d'article | VVX07H005A00 |
| Marque | Panasonic |
| Taille | 7.0 |
| application | PAD |
| Résolution | 800×1280 |
| Composition | LCM |
| Luminosité | 450 |
| CR | 1000:1 |
| Couleurs | 262K |
| Rétroéclairage | WLED |
| Interface | MIPI |
| marque de panneau | Panasonic |
| modèle de panneau | VVX07H005A00 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 7.0 inch |
| résolution | 800(RGB)×1280 , WXGA |
| mode d'affichage | IPS, Normally Black, Transmissive |
| zone active | 94.2×150.72 mm |
| contour | 104.32×161.67×3.8 mm |
| surface | Hard coating |
| luminosité | 450 cd/m² (Typ.) |
| Rapport de contraste | 1000:1 (Typ.) |
| couleurs d'affichage | 262K (6-bit) |
| Temps de réponse | 30 (Max.)(Tr+Td) |
| angle de vue | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 5S5PWLEDWithout Driver |
| interface de signaux | MIPI (4 data lanes), 34 pins |
| tension d'entrée | 1.8/3.3V (Typ.)(VCC/VDD) |
