| Numéro d'article | NL10276AC30-07 |
| Marque | NLT |
| Taille | 15.0 |
| application | DMPC |
| Résolution | 1024×768 |
| Composition | LCM |
| Luminosité | 400 |
| CR | 300:1 |
| Couleurs | 16.7M |
| Rétroéclairage | CCFL |
| Interface | TTL |
| marque de panneau | NEC |
| modèle de panneau | NL10276AC30-07 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 15.0 inch |
| résolution | 1024(RGB)×768 , XGA |
| mode d'affichage | Normally Black, Transmissive |
| zone active | 304.128×228.096 mm |
| contour | 330×256×30 mm |
| surface | Hard coating (2H) |
| luminosité | 400 cd/m² (Typ.) |
| Rapport de contraste | 300:1 (Typ.) |
| couleurs d'affichage | 16.7M (6-bit + Hi-FRC), CIE193160% |
| Temps de réponse | 10/10 (Typ.)(Tr/Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 8 pcsCCFLEmbedded (Inverter) |
| interface de signaux | TTL (2 ch, 8-bit), 75 pins |
| tension d'entrée | 5.0V (Typ.) |
