| Numéro d'article | LQ150X1DG11 |
| Marque | SHARP |
| Taille | 15.0 |
| application | DMPC |
| Résolution | 1024×768 |
| Composition | LCM |
| Luminosité | 200 |
| CR | 300:1 |
| Couleurs | 262K |
| Rétroéclairage | CCFL |
| Interface | TTL |
| marque de panneau | SHARP |
| modèle de panneau | LQ150X1DG11 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 15.0 inch |
| résolution | 1024(RGB)×768 , XGA |
| mode d'affichage | TN, Normally White, Transmissive |
| zone active | 304.128×228.096 mm |
| contour | 331.3×257.9 mm |
| surface | Antiglare (Haze 28%), Hard coating (2H) |
| luminosité | 200 cd/m² (Typ.) |
| Rapport de contraste | 300:1 (Typ.) |
| couleurs d'affichage | 262K (6-bit) |
| Temps de réponse | 10/35 (Typ.)(Tr/Td) |
| angle de vue | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 2 pcsCCFLWithout Driver |
| interface de signaux | Parallel RGB (2 ch, 6-bit), 60 pins |
| tension d'entrée | 5.0V (Typ.)(VCC) |
