| Numéro d'article | TX38D14VC0CAA |
| Marque | KOE |
| Taille | 15.0 |
| application | DMPC |
| Résolution | 1024×768 |
| Composition | LCM |
| Luminosité | 200 |
| CR | 300:1 |
| Couleurs | 16.7M |
| Rétroéclairage | CCFL |
| Interface | LVDS |
| marque de panneau | HITACHI |
| modèle de panneau | TX38D14VC0CAA |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 15.0 inch |
| résolution | 1024(RGB)×768 , XGA |
| mode d'affichage | IPS, Normally Black, Transmissive |
| zone active | 304.128×228.096 mm |
| contour | 350×265 mm |
| surface | |
| luminosité | 200 cd/m² (Typ.) |
| Rapport de contraste | 300:1 (Typ.) |
| couleurs d'affichage | 16.7M (8-bit) |
| Temps de réponse | 25/25 (Typ.)(Tr/Td) |
| angle de vue | 80/80/80/80 (Min.)(CR≥20)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 4 pcsCCFLWithout Driver |
| interface de signaux | LVDS (1 ch, 8-bit), 20 pins |
| tension d'entrée | 5.0V (Typ.) |
