| Numéro d'article | HSD101JFW1-C11 |
| Marque | HannStar |
| Taille | 10.1 |
| application | Automotive Display |
| Résolution | 1024×600 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.2M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | HannStar |
| modèle | HSD101JFW1-C11 |
| taille diagonale | 10.1 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1024(RGB)×600 [WSVGA] 117PPI |
| configuration | RGB Vertical Stripe |
| zone active | 222.72(H)×125.28(V) mm |
| contour sombre. | 235(H)×143(V) ×6.3(D) mm |
| zone de lunette | 226(H)×128.5(V) mm |
| traitement | Hard coating (3H) |
| luminosité | 500 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 25 (Typ.)(Tr+Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10) |
| mode de fonctionnement | IPS Pro, Normally Black, Transflective |
| couleur de soutien | 16.2M 45% NTSC |
| Source de lumière | WLED [6S7P] , 20K hours , W/O Driver |
| lester | 265/275g (Typ./Max.) |
| conçu pour | Automotive Display |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | LVDS (1 ch, 8-bit) , 60 pins FPC |
| source de courant | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| environnement | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
