| Numéro d'article | TM035NDH04 |
| Marque | Tianma |
| Taille | 3.5 |
| application | HHP |
| Résolution | 272×480 |
| Composition | LCM |
| Luminosité | 300 |
| CR | 500:1 |
| Couleurs | 65K/262K |
| Rétroéclairage | WLED |
| Interface | CPU |
| marque de panneau | TIANMA |
| modèle de panneau | TM035NDH04 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 3.5 inch |
| résolution | 272(RGB)×480 , WQVGA |
| mode d'affichage | TN, Normally White, Transmissive |
| zone active | 43.86×77.4 mm |
| contour | 50.86×87.98×2.5 mm |
| surface | Antiglare |
| luminosité | 300 cd/m² (Typ.) |
| Rapport de contraste | 500:1 (Typ.) |
| couleurs d'affichage | 65K/262K , CIE193150% |
| Temps de réponse | 20 (Typ.)(Tr+Td) |
| angle de vue | 60/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| type de lampe | 1S6PWLEDWithout Driver |
| interface de signaux | CPU, 41 pins |
| tension d'entrée | 2.8/2.8V (Typ.)(IOVCC/VCC) |
