| Numéro d'article | TCG121XGLPAPNN-AN20-S |
| Marque | Kyocera |
| Taille | 12.1 |
| application | Industrial |
| Résolution | 1024×768 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 750:1 |
| Couleurs | 262K/16.2M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | Kyocera |
| modèle | TCG121XGLPAPNN-AN20-S |
| taille diagonale | 12.1 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1024(RGB)×768 [XGA] 105PPI |
| configuration | RGB Vertical Stripe |
| zone active | 245.76(H)×184.32(V) mm |
| contour sombre. | 260.5(H)×203.4(V) ×10.8(D) mm |
| zone de lunette | 249.0(H)×187.5(V) mm |
| traitement | Antiglare |
| luminosité | 500 cd/m² (Typ.) |
| Rapport de contraste | 750:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 18/12 (Typ.)(Tr/Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10) |
| mode de fonctionnement | AWV, Normally Black, Transmissive |
| couleur de soutien | 262K/16.2M 50% NTSC |
| Source de lumière | WLED , 50K hours , With LED Driver |
| lester | 670g |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
| AA121SL09 | Mitsubishi | 12.1 | 800×600 |
| AA121SL12 | Mitsubishi | 12.1 | 800×600 |
| AA121TD02 | Mitsubishi | 12.1 | 1280×800 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LM12S472 | SHARP | 12.1 | 800×600 |
| LMG9980ZWCC-01 | KOE | 12.1 | 800×600 |
| LP121WX3-TLA1 | LG Display | 12.1 | 1280×800 |
| LTD121EWEK | TOSHIBA | 12.1 | 1280×800 |
| N121I7-L01 | Innolux | 12.1 | 1280×800 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
