| Numéro d'article | T500DB01 V0 |
| Marque | AUO |
| Taille | 50 |
| application | LCTV |
| Résolution | 2560×1080 |
| Composition | LCM |
| Luminosité | 400 |
| CR | 4000:1 |
| Couleurs | 1.07B |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque de panneau | AUO |
| modèle de panneau | T500DB01 V0 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 50 inch |
| résolution | 2560(RGB)×1080 , CSHD |
| mode d'affichage | AMVA3, Normally Black, Transmissive |
| zone active | 1171.2×491.1 mm |
| contour | 1214.2×540.6 mm |
| surface | |
| luminosité | 400 cd/m² (Typ.) |
| Rapport de contraste | 4000:1 (Typ.) |
| couleurs d'affichage | 1.07B (10-bit), CIE193172% |
| Temps de réponse | 5.5 (Typ.)(G to G) |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 120Hz |
| type de lampe | WLEDEmbedded (LED Driver) |
| interface de signaux | LVDS (4 ch, 10-bit), 92 pins |
| tension d'entrée | 12.0V (Typ.) |
