| Numéro d'article | T315XW06 V5 |
| Marque | AUO |
| Taille | 31.5 |
| application | LCTV |
| Résolution | 1366×768 |
| Composition | LCM |
| Luminosité | 350 |
| CR | 3000:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque de panneau | AUO |
| modèle de panneau | T315XW06 V5 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 31.5 inch |
| résolution | 1366(RGB)×768 , WXGA |
| mode d'affichage | AMVA, Normally Black, Transmissive |
| zone active | 697.685×392.256 mm |
| contour | 735.4×433 mm |
| surface | Antiglare (Haze 2%), Hard coating (3H) |
| luminosité | 350 cd/m² (Typ.) |
| Rapport de contraste | 3000:1 (Typ.) |
| couleurs d'affichage | 16.7M (8-bit), CIE193172% |
| Temps de réponse | 6.5 (Typ.)(G to G) |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | WLEDEmbedded (LED Driver) |
| interface de signaux | LVDS (1 ch, 8-bit), 30 pins |
| tension d'entrée | 12.0V (Typ.) |
