| Numéro d'article | T260XW02 VB |
| Marque | AUO |
| Taille | 26.0 |
| application | LCTV |
| Résolution | 1366×768 |
| Composition | LCM |
| Luminosité | 500 |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | CCFL |
| Interface | LVDS |
| marque de panneau | AUO |
| modèle de panneau | T260XW02 VB 0 Compatible model |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 26.0 inch |
| résolution | 1366(RGB)×768 , WXGA |
| mode d'affichage | VA, Normally Black, Transmissive |
| zone active | 575.769×323.712 mm |
| contour | 626×373 mm |
| surface | Antiglare (Haze 13%), Hard coating (3H) |
| luminosité | 500 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) |
| couleurs d'affichage | 16.7M (8-bit), CIE193172% |
| Temps de réponse | 21/4 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 14 pcsCCFLEmbedded (Inverter) |
| interface de signaux | LVDS (1 ch, 8-bit), 30 pins |
| tension d'entrée | 12.0V (Typ.) |
