| Numéro d'article | NL6448AC20-06 |
| Marque | NLT |
| Taille | 6.5 |
| application | IA |
| Résolution | 640×480 |
| Composition | LCM |
| Luminosité | 200 |
| CR | 150:1 |
| Couleurs | 4096/262K |
| Rétroéclairage | CCFL |
| Interface | TTL |
| marque de panneau | NEC |
| modèle de panneau | NL6448AC20-06 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 6.5 inch |
| résolution | 640(RGB)×480 , VGA |
| mode d'affichage | TN, Normally White, Transmissive |
| zone active | 132.48×99.36 mm |
| contour | 178.8×126.8 mm |
| surface | |
| luminosité | 200 cd/m² (Typ.) |
| Rapport de contraste | 150:1 (Typ.) |
| couleurs d'affichage | 4096/262K (4-bit / 6-bit), CIE193145% |
| Temps de réponse | 40 (Typ.)(Tr) |
| angle de vue | 50/50/35/45 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 2 pcsCCFLEmbedded (Inverter) |
| interface de signaux | CMOS (1 ch, 4/6-bit), 31 pins |
| tension d'entrée | 5.0V (Typ.) |
