| Numéro d'article | NL10276AC30-03 |
| Marque | NLT |
| Taille | 15.0 |
| application | DMPC |
| Résolution | 1024×768 |
| Composition | LCM |
| Luminosité | 200 |
| CR | 200:1 |
| Couleurs | Full color |
| Rétroéclairage | CCFL |
| Interface | Analog |
| marque de panneau | NEC |
| modèle de panneau | NL10276AC30-03 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 15.0 inch |
| résolution | 1024(RGB)×768 , XGA |
| mode d'affichage | TN, Normally White, Transmissive |
| zone active | 304.128×228.096 mm |
| contour | 350×265×20.5 mm |
| surface | |
| luminosité | 200 cd/m² (Typ.) |
| Rapport de contraste | 200:1 (Typ.) |
| couleurs d'affichage | Full color , CIE193142% |
| Temps de réponse | 15/40 (Typ.)(Tr/Td) |
| angle de vue | 55/55/50/45 (Typ.)(CR≥10)(L/R/U/D) |
| type de lampe | 2 pcsCCFLEmbedded (Inverter) |
| interface de signaux | Analog RGB, 41 pins |
| tension d'entrée | 12.0V (Typ.) |
| NL10276AC24-05 | NLT | 12.1 | 1024×768 |
| NL10276AC28-05R | NLT | 14.1 | 1024×768 |
| NL10276AC30-03 | NLT | 15.0 | 1024×768 |
| NL10276AC30-04R | NLT | 15.0 | 1024×768 |
| NL10276AC30-42C | NLT | 15.0 | 1024×768 |
| NL10276BC12-02 | NLT | 6.3 | 1024×768 |
| NL10276BC20-04 | NLT | 10.4 | 1024×768 |
| NL10276BC24-13 | NLT | 12.1 | 1024×768 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| NL10276BC30-34D | NLT | 15.0 | 1024×768 |
| FLC44SXC8V | Fujitsu | 17.4 | 1280×1024 |
| LM170E01-TLB3 | LG Display | 17.0 | 1280×1024 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| LM200WD3-TLA1 | LG Display | 20.0 | 1600×900 |
| LM201W01-B6K1 | LG Display | 20.1 | 1680×1050 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM213U3-L07 | Samsung | 21.3 | 1600×1200 |
| M170EG01 VF | AUO | 17.0 | 1280×1024 |
| M240UW04 V1 | AUO | 24.0 | 1920×1200 |
| NL160120BC27-09 | NLT | 21.3 | 1600×1200 |
