| Numéro d'article | N070ICE-GB1 |
| Marque | Innolux |
| Taille | 7.0 |
| application | PAD |
| Résolution | 800×1280 |
| Composition | LCM |
| Luminosité | 300 |
| CR | 1000:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | MIPI |
| marque de panneau | INNOLUX |
| modèle de panneau | N070ICE-GB1 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 7.0 inch |
| résolution | 800(RGB)×1280 , WXGA |
| mode d'affichage | IPS, Normally Black, Transmissive |
| zone active | 94.2×150.72 mm |
| contour | 105.62×163.27×3.95 mm |
| surface | Glare (Haze 0%), Hard coating (3H) |
| luminosité | 300 cd/m² (Typ.) |
| Rapport de contraste | 1000:1 (Typ.) |
| couleurs d'affichage | 16.7M (8-bit) |
| Temps de réponse | 14/11 (Typ.)(Tr/Td) |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 3S6PWLEDWithout Driver |
| interface de signaux | MIPI (4 data lanes), 36 pins |
| tension d'entrée | 1.8/3.3V (Typ.)(VCC/VDD) |
