| Numéro d'article | M270HCJ-L5B |
| Marque | Innolux |
| Taille | 27.0 |
| application | Desktop Monitor |
| Résolution | 1920×1080 |
| Composition | a-Si TFT-LCD , LCM |
| Luminosité | |
| CR | 1000:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | Innolux |
| taille diagonale | 27.0 inch |
| format pixel | 1920(RGB)×1080 [FHD] 81PPI |
| zone active | 597.888(H)×336.312(V) mm |
| zone de lunette | - |
| luminosité | 250 cd/m² (Typ.) |
| direction de la vue | Symmetry |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10) |
| couleur de soutien | 16.7M 72% NTSC |
| lester | 2.87/3.01Kgs (Typ./Max.) |
| fréquence d'images | 60Hz |
| type d'interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| source de courant | 5.0V (Typ.) |
| environnement | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| modèle | M270HCJ-L5B |
| taper | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| contour sombre. | 607.1(H)×354.1(V) ×13.7(D) mm |
| traitement | Antiglare (Haze 25%), Hard coating (3H) |
| Rapport de contraste | 1000:1 (Typ.) (TM) |
| Temps de réponse | 8/7 (Typ.)(Tr/Td) |
| mode de fonctionnement | AAS, Normally Black, Transmissive |
| Source de lumière | WLED [4 strings] , 30K hours , W/O Driver |
| conçu pour | Desktop Monitor |
| Ecran tactile | Without |
