| Numéro d'article | M238KCJ-L5B |
| Marque | Innolux |
| Taille | 23.8 |
| application | Desktop Monitor |
| Résolution | 2560×1440 |
| Composition | a-Si TFT-LCD , LCM |
| Luminosité | |
| CR | 1000:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | Innolux |
| taille diagonale | 23.8 inch |
| format pixel | 2560(RGB)×1440 [Quad-HD] 123PPI |
| zone active | 525.696(H)×295.704(V) mm |
| zone de lunette | - |
| luminosité | 300 cd/m² (Typ.) |
| direction de la vue | Symmetry |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10) |
| couleur de soutien | 16.7M 95% DCI-P3 |
| lester | 2.40/2.52Kgs (Typ./Max.) |
| fréquence d'images | 60Hz |
| type d'interface | LVDS (4 ch, 8-bit) , 92 pins Connector |
| source de courant | 10.0V (Typ.) |
| environnement | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| modèle | M238KCJ-L5B |
| taper | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| contour sombre. | 536.3(H)×313.7(V) ×14.9(D) mm |
| traitement | Antiglare (Haze 25%), Hard coating (3H) |
| Rapport de contraste | 1000:1 (Typ.) (TM) |
| Temps de réponse | 8/7 (Typ.)(Tr/Td) |
| mode de fonctionnement | AAS, Normally Black, Transmissive |
| Source de lumière | WLED , 30K hours , W/O Driver |
| conçu pour | Desktop Monitor |
| Ecran tactile | Without |
