| Numéro d'article | M238HCA-LCZ |
| Marque | Innolux |
| Taille | 23.8 |
| application | Desktop Monitor Gami |
| Résolution | 1920×1080 |
| Composition | a-Si TFT-LCD , LCM |
| Luminosité | |
| CR | 1000:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | Innolux |
| taille diagonale | 23.8 inch |
| format pixel | 1920(RGB)×1080 [FHD] 92PPI |
| zone active | 527.04(H)×296.46(V) mm |
| zone de lunette | - |
| luminosité | 250 cd/m² (Typ.) |
| direction de la vue | Symmetry |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10) |
| couleur de soutien | 16.7M 99% sRGB |
| lester | 2.23/2.34Kgs (Typ./Max.) |
| fréquence d'images | 60Hz |
| type d'interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| source de courant | 5.0V (Typ.) |
| environnement | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| modèle | M238HCA-LCZ |
| taper | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| contour sombre. | 535(H)×313(V) ×12.7(D) mm |
| traitement | Antiglare (Haze 25%), Hard coating (3H) |
| Rapport de contraste | 1000:1 (Typ.) (TM) |
| Temps de réponse | 14 (Typ.)(G to G) |
| mode de fonctionnement | AAS, Normally Black, Transmissive |
| Source de lumière | WLED [4 strings] , 30K hours , W/O Driver |
| conçu pour | Desktop Monitor Gaming |
| Ecran tactile | Without |
| LM238WF1-SLE1 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSF1 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSG2 | LG Display | 23.8 | 1920×1080 |
| LM238WF2-SSK1 | LG Display | 23.8 | 1920×1080 |
| LM238WF4-SSA1 | LG Display | 23.8 | 1920×1080 |
| LM238WR1-SLA1 | LG Display | 23.8 | 3840×2160 |
| LM238WR2-SLA1 | LG Display | 23.8 | 3840×2160 |
| M238HAN01.0 | AUO | 23.8 | 1920×1080 |
| M238HVN01.0 | AUO | 23.8 | 1920×1080 |
| MV238FHM-N10 | BOE | 23.8 | 1920×1080 |
