| Numéro d'article | M101GWWF R0 |
| Marque | IVO |
| Taille | 10.1 |
| application | Laptop |
| Résolution | 1280×800 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | IVO |
| modèle | M101GWWF R0 |
| taille diagonale | 10.1 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1280(RGB)×800 [WXGA] 149PPI |
| configuration | RGB Vertical Stripe |
| zone active | 216.96(H)×135.6(V) mm |
| contour sombre. | 229.46(H)×149.1(V) ×4.56(D) mm |
| zone de lunette | - |
| traitement | Glare (Haze 0%), Hard coating (3H) |
| luminosité | 350 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 25 (Typ.)(Tr+Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10) |
| mode de fonctionnement | IPS, Normally Black, Transmissive |
| couleur de soutien | 16.7M |
| Source de lumière | WLED , 25K hours , With LED Driver |
| style de formulaire | Slim (PCBA Bent, T≤3.0mm) |
| conçu pour | Laptop |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | LVDS (1 ch, 8-bit) , 40 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
