| Numéro d'article | LTY400HF06 |
| Marque | Samsung |
| Taille | 40 |
| application | LCTV |
| Résolution | 1920×1080 |
| Composition | LCM |
| Luminosité | 400 |
| CR | 5000:1 |
| Couleurs | 1.07B |
| Rétroéclairage | CCFL |
| Interface | LVDS |
| marque de panneau | SAMSUNG |
| modèle de panneau | LTY400HF06 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 40 inch |
| résolution | 1920(RGB)×1080 , FHD |
| mode d'affichage | S-PVA, Normally Black, Transmissive |
| zone active | 885.6×498.15 mm |
| contour | 952×551×61.2 mm |
| surface | Antiglare (Haze 4.5%), Hard coating (3H) |
| luminosité | 400 cd/m² (Typ.) |
| Rapport de contraste | 5000:1 (Typ.) |
| couleurs d'affichage | 1.07B (8-bit + Hi-FRC), CIE193172% |
| Temps de réponse | 12/6 (Typ.)(Tr/Td); 6.5 (Typ.)(G to G) |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| type de lampe | 10 pcsCCFLEmbedded (Inverter) |
| interface de signaux | LVDS (2 ch, 10-bit), 55 pins |
| tension d'entrée | 12.0V (Typ.) |
