| Numéro d'article | LTN133YL01-F01 |
| Marque | Samsung |
| Taille | 13.3 |
| application | NBPC |
| Résolution | 3200×1800 |
| Composition | LCM |
| Luminosité | 350 |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | eDP |
| marque de panneau | SAMSUNG |
| modèle de panneau | LTN133YL01-F01 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 13.3 inch |
| résolution | 3200RG(BW)×1800 , Quad-HD+ |
| mode d'affichage | PLS, Normally Black, Transmissive |
| zone active | 293.44×165.06 mm |
| contour | 306.15×188.2 mm |
| style de forme | Slim (PCBA Flat, Depth ≤3.2mm) |
| surface | |
| luminosité | 350 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) |
| couleurs d'affichage | 16.7M (8-bit), CIE193172% |
| Temps de réponse | 16 (Typ.)(Tr+Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 11S5PWLEDEmbedded (LED Driver) |
| interface de signaux | eDP (4 Lanes), 40 pins |
| tension d'entrée | 3.3V (Typ.) |
