| Numéro d'article | LQ156M1JW16 |
| Marque | Sharp |
| Taille | 15.6 |
| application | Laptop Gaming |
| Résolution | 1920×1080 |
| Composition | Oxide TFT-LCD, LCM |
| Luminosité | |
| CR | 1000:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | eDP |
| marque | Sharp |
| modèle | LQ156M1JW16 (SHP14F4) |
| taille diagonale | 15.6 inch |
| taper | Oxide TFT-LCD, LCM |
| format pixel | 1920(RGB)×1080 [FHD] 141PPI |
| configuration | RGB Vertical Stripe |
| zone active | 344.16(H)×193.59(V) mm |
| contour sombre. | 350.66(H)×215.54(V) ×2.6(D) mm |
| zone de lunette | - |
| traitement | Antiglare, Hard coating (2H) |
| luminosité | 300 cd/m² (Typ.) |
| Rapport de contraste | 1000:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 7.5/3.5 (Typ.)(Tr/Td) |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10) |
| mode de fonctionnement | New Mode2, Normally Black, Transmissive |
| couleur de soutien | 16.7M 100% sRGB |
| Source de lumière | WLED , 15K hours , With LED Driver |
| style de formulaire | Slim (PCBA Flat, T≤3.2mm) |
| conçu pour | Laptop Gaming |
| fréquence d'images | 240Hz |
| Ecran tactile | Without |
| type d'interface | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -25 ~ 60 °C |
