| Numéro d'article | LQ043T1DG04 |
| Marque | SHARP |
| Taille | 4.3 |
| application | PND |
| Résolution | 480×272 |
| Composition | LCM |
| Luminosité | 350 |
| CR | 500:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | TTL |
| marque de panneau | SHARP |
| modèle de panneau | LQ043T1DG04 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 4.3 inch |
| résolution | 480×272(RGB) , WQVGA |
| mode d'affichage | TN, Normally White, Transmissive |
| zone active | 95.04×53.856 mm |
| contour | 105.5×67.2 mm |
| surface | |
| luminosité | 350 cd/m² (Typ.) |
| Rapport de contraste | 500:1 (Typ.) |
| couleurs d'affichage | 16.7M (8-bit) |
| Temps de réponse | 8/20 (Typ.)(Tr/Td) |
| angle de vue | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| type de lampe | 9S1PWLEDWithout Driver |
| interface de signaux | Parallel RGB (1 ch, 8-bit), 40 pins |
| tension d'entrée | 3.3V (Typ.)(VCI) |
