| Numéro d'article | LM230WF5-TLG1 |
| Marque | LG Display |
| Taille | 23.0 |
| application | DMPC |
| Résolution | 1920×1080 |
| Composition | LCM |
| Luminosité | 250 |
| CR | 1000:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque de panneau | LG Display |
| modèle de panneau | LM230WF5-TLG1 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 23.0 inch |
| résolution | 1920(RGB)×1080 , FHD |
| mode d'affichage | TN, Normally White, Transmissive |
| zone active | 509.184×286.416 mm |
| contour | 533.2×312×10.7 mm |
| surface | Glare (Haze 0%), Hard coating (2H) |
| luminosité | 250 cd/m² (Typ.) |
| Rapport de contraste | 1000:1 (Typ.) |
| couleurs d'affichage | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Temps de réponse | 1.3/3.7 (Typ.)(Tr/Td) |
| angle de vue | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 2 stringsWLEDWithout Driver |
| interface de signaux | LVDS (2 ch, 8-bit), 30 pins |
| tension d'entrée | 5.0V (Typ.) |
