| Numéro d'article | LM133LF9L01 |
| Marque | PANDA |
| Taille | 13.3 |
| application | Laptop |
| Résolution | 1920×1080 |
| Composition | Oxide TFT-LCD, LCM |
| Luminosité | |
| CR | 1000:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | eDP |
| marque | PANDA |
| modèle | LM133LF9L01 (NCP0049) |
| taille diagonale | 13.3 inch |
| taper | Oxide TFT-LCD, LCM |
| format pixel | 1920(RGB)×1080 [FHD] 166PPI |
| configuration | RGB Vertical Stripe |
| zone active | 293.76(H)×165.24(V) mm |
| contour sombre. | 300.26(H)×177.35(V) ×4.35(D) mm |
| zone de lunette | - |
| traitement | Antiglare |
| luminosité | 250 cd/m² (Typ.) |
| Rapport de contraste | 1000:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 25 (Typ.)(Tr+Tf) |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10) |
| mode de fonctionnement | FFS, Normally Black, Transmissive |
| couleur de soutien | 16.7M 70% NTSC |
| Source de lumière | WLED , 15K hours , With LED Driver |
| style de formulaire | Slim (PCBA Bent, T≤3.0mm) |
| conçu pour | Laptop |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
