| Numéro d'article | LC470DUE-SFU2 |
| Marque | LG Display |
| Taille | 47 |
| application | LCTV |
| Résolution | 1920×1080 |
| Composition | LCM |
| Luminosité | 300 |
| CR | 1200:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque de panneau | LG Display |
| modèle de panneau | LC470DUE-SFU2 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 47 inch |
| résolution | 1920(RGB)×1080 , FHD |
| mode d'affichage | IPS, Normally Black, Transmissive |
| zone active | 1039.68×584.82 mm |
| contour | 1068×617.8 mm |
| surface | Antiglare (Haze 1%), Hard coating (2H) |
| luminosité | 300 cd/m² (Typ.) |
| Rapport de contraste | 1200:1 (Typ.) |
| couleurs d'affichage | 16.7M (8-bit), CIE193168% |
| Temps de réponse | 9 (Typ.)(G to G)(B/W) |
| angle de vue | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | WLEDWithout Driver |
| interface de signaux | LVDS (2 ch, 8-bit), 51 pins |
| tension d'entrée | 12.0V (Typ.) |
| LC470DUE-FGA3 | LG Display | 47 | 1920×1080 |
| LC470DUE-SFR1 | LG Display | 47 | 1920×1080 |
| LC470DUE-SFU2 | LG Display | 47 | 1920×1080 |
| LC470DUN-SFU2 | LG Display | 47 | 1920×1080 |
| LC470DUT-SEF2 | LG Display | 47 | 1920×1080 |
| LC470EUF-FFP1 | LG Display | 47 | 1920×1080 |
| LC470EUF-PEF1 | LG Display | 47 | 1920×1080 |
| LC470EUF-SDF1 | LG Display | 47 | 1920×1080 |
| LC470EUG-PFF1 | LG Display | 47 | 1920×1080 |
| LC470WUD-SCM1 | LG Display | 47 | 1920×1080 |
| LC420EUE-SEM1 | LG Display | 42 | 1920×1080 |
| LC470DUN-SFU2 | LG Display | 47 | 1920×1080 |
| LC550EQE-PGF1 | LG Display | 55 | 3840×2160 |
| LC650EGE-FHM1 | LG Display | 65 | 3840×2160 |
| LM315TA6A | PANDA | 31.5 | 1366×768 |
| LTA220W1-L02 | Samsung | 22.0 | 1280×720 |
| LTA320HN02-W | Samsung | 31.5 | 1920×1080 |
| LTA400HA11 | Samsung | 40 | 1920×1080 |
| T315HW02 VB | AUO | 31.5 | 1920×1080 |
| V400HJ6-ME2 | Innolux | 40 | 1920×1080 |
