| Numéro d'article | LA123WF4-SR03 |
| Marque | LG Display |
| Taille | 12.3 |
| application | Automotive Display |
| Résolution | 1920×720 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | RSDS |
| marque | LG Display |
| modèle | LA123WF4-SR03 |
| taille diagonale | 12.3 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1920(RGB)×720 167PPI |
| configuration | RGB Vertical Stripe |
| zone active | 292.032(H)×109.512(V) mm |
| contour sombre. | 310(H)×128(V) ×10.75(D) mm |
| zone de lunette | 296.03(H)×113.5(V) mm |
| traitement | Hard coating |
| luminosité | 600 cd/m² (Min.) |
| Rapport de contraste | 800:1 (Min.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| angle de vue | 89/89/89/89 (Min.)(CR≥10) |
| mode de fonctionnement | IPS, Normally Black, Transmissive |
| couleur de soutien | 16.7M 77% NTSC |
| Source de lumière | WLED [11S4P] , 10K hours , W/O Driver |
| lester | 385/400g (Typ./Max.) |
| conçu pour | Automotive Display |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | RSDS (2 Channel) , 110 pins FPC |
| source de courant | 3.3/13.0V (Typ.)(VCC/VDD) |
| environnement | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
