| Numéro d'article | HT260WX2-101 |
| Marque | BOE |
| Taille | 26.0 |
| application | LCTV |
| Résolution | 1366×768 |
| Composition | CELL |
| Luminosité | 0 |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | No B/L |
| Interface | LVDS |
| marque de panneau | BOE |
| modèle de panneau | HT260WX2-101 |
| type de panneau | a-Si TFT-LCD , CELL |
| taille du panneau | 26.0 inch |
| résolution | 1366(RGB)×768 , WXGA |
| mode d'affichage | TN, Normally White, Transmissive |
| zone active | 575.769×323.712 mm |
| contour | 592×339.8 mm |
| surface | Antiglare (Haze 25%), Hard coating (3H) |
| profondeur de verre | 0.70+0.70 mm |
| transmissivité | 7.05% (Typ.)(with Polarizer) |
| Rapport de contraste | 800:1 (Typ.) |
| couleurs d'affichage | 16.7M (6-bit + Hi-FRC), CIE193172% |
| Temps de réponse | 5 (Typ.)(G to G) |
| angle de vue | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| interface de signaux | LVDS (1 ch, 8-bit), 30 pins |
| tension d'entrée | 12.0V (Typ.) |
