| Numéro d'article | HT121WX2-210 |
| Marque | HYDIS |
| Taille | 12.1 |
| application | PAD |
| Résolution | 1280×800 |
| Composition | LCM |
| Luminosité | 200 |
| CR | 600:1 |
| Couleurs | 262K |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque de panneau | HYDIS |
| modèle de panneau | HT121WX2-210 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 12.1 inch |
| résolution | 1280(RGB)×800 , WXGA |
| mode d'affichage | TN, Normally White, Transmissive |
| zone active | 261.12×163.2 mm |
| contour | 276.8×180×6.8 mm |
| surface | Glare (Haze 0%) |
| luminosité | 200 cd/m² (Typ.) |
| Rapport de contraste | 600:1 (Typ.) |
| couleurs d'affichage | 262K (6-bit) |
| Temps de réponse | 10/15 (Typ.)(Tr/Td) |
| angle de vue | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 12S4PWLEDEmbedded (LED Driver) |
| interface de signaux | LVDS (1 ch, 6-bit), 40 pins |
| tension d'entrée | 3.3V (Typ.) |
