| Numéro d'article | HSD150GXN1-A00-C00 |
| Marque | HannStar |
| Taille | 15.0 |
| application | Industrial |
| Résolution | 1024×768 |
| Composition | a-Si TFT-LCD , LCM |
| Luminosité | |
| CR | 700:1 |
| Couleurs | 262K/16.2M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | HannStar |
| taille diagonale | 15.0 inch |
| format pixel | 1024(RGB)×768 [XGA] 85PPI |
| zone active | 304.128(H)×228.096(V) mm |
| zone de lunette | 307.4(H)×231.3(V) mm |
| luminosité | 250 cd/m² (Typ.) |
| direction de la vue | - |
| angle de vue | 80/80/60/80 (Typ.)(CR≥10) |
| couleur de soutien | 262K/16.2M 60% NTSC |
| lester | 1.20Kgs (Max.) |
| fréquence d'images | 60Hz |
| type d'interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
| modèle | HSD150GXN1-A00-C00 |
| taper | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| contour sombre. | 326.5(H)×253.5(V) ×12.7(D) mm |
| traitement | - |
| Rapport de contraste | 700:1 (Typ.) (TM) |
| Temps de réponse | 12 (Typ.)(Tr+Td) |
| mode de fonctionnement | TN, Normally White, Transmissive |
| Source de lumière | WLED , 30K hours , With LED Driver |
| conçu pour | Industrial |
| Ecran tactile | Embeded Touch |
