| Numéro d'article | HGS128647-Y-EH-LV |
| Marque | Other |
| Taille | 1.54 |
| application | IA |
| Résolution | 128×64 |
| Composition | OLED |
| Luminosité | 150 |
| CR | 2000:1 |
| Couleurs | Mono(Yellow) |
| Rétroéclairage | self |
| Interface | CPU/SPI/I²C |
| marque de panneau | TSINGTEK |
| modèle de panneau | HGS128647-Y-EH-LV |
| type de panneau | PM-OLED , OLED |
| taille du panneau | 1.54 inch |
| résolution | 128×64 |
| zone active | 35.056×17.52 mm |
| contour | 54×39.5×8.5 mm |
| surface | |
| luminosité | 150 cd/m² (Typ.) |
| Rapport de contraste | 2000 : 1 (Min.) |
| couleurs d'affichage | Mono(Yellow) |
| angle de vue | 80/80/80/80 (Min.)(L/R/U/D) |
| pilote ic | Built-in SSD1305 |
| interface de signaux | 8-bit 6800/8080 parallel, 4-wire SPI, I²C, 20 pins |
| tension d'entrée | 3.3V (Typ.) |
