| Numéro d'article | HB140WH1-504 |
| Marque | BOE |
| Taille | 14.0 |
| application | NBPC |
| Résolution | 1366×768 |
| Composition | LCM |
| Luminosité | 220 |
| CR | 600:1 |
| Couleurs | 262K |
| Rétroéclairage | WLED |
| Interface | eDP |
| marque de panneau | BOE |
| modèle de panneau | HB140WH1-504 |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 14.0 inch |
| résolution | 1366(RGB)×768 , WXGA |
| mode d'affichage | TN, Normally White, Transmissive |
| zone active | 309.399×173.952 mm |
| contour | 320.9×187.6 mm |
| style de forme | Slim (PCBA Flat, Depth ≤3.2mm) |
| surface | Hard coating (7H) |
| luminosité | 220 cd/m² (Typ.) |
| Rapport de contraste | 600:1 (Typ.) |
| couleurs d'affichage | 262K (6-bit), CIE193145% |
| Temps de réponse | 12 (Typ.)(Tr+Td) |
| angle de vue | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 8S4PWLEDEmbedded (LED Driver) |
| interface de signaux | eDP (1 Lane), 40 pins |
| tension d'entrée | 3.3V (Typ.) |
