| Numéro d'article | GV185FHM-N10-3M30 |
| Marque | BOE |
| Taille | 18.5 |
| application | Industrial |
| Résolution | 1920×1080 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 1200:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | BOE |
| modèle | GV185FHM-N10-3M30 |
| taille diagonale | 18.5 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1920(RGB)×1080 [FHD] 119PPI |
| configuration | RGB Vertical Stripe |
| zone active | 408.96(H)×230.04(V) mm |
| contour sombre. | 430.4(H)×254.6(V) ×12.5(D) mm |
| zone de lunette | 410.96(H)×232.04(V) mm |
| traitement | Antiglare (Haze 25%), Hard coating (3H) |
| luminosité | 350 cd/m² (Typ.) |
| Rapport de contraste | 1200:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 30 (Typ.)(Tr+Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10) |
| mode de fonctionnement | ADS, Normally Black, Transmissive |
| couleur de soutien | 16.7M 70% NTSC |
| Source de lumière | WLED [11S4P] , With LED Driver |
| lester | 1.80Kgs (Typ.) |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| source de courant | 5.0V (Typ.) |
| environnement | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
