| Numéro d'article | G156XTN01.0 |
| Marque | AUO |
| Taille | 15.6 |
| application | Industrial |
| Résolution | 1366×768 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | AUO |
| modèle | G156XTN01.0 |
| taille diagonale | 15.6 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1366(RGB)×768 [WXGA] 100PPI |
| configuration | RGB Vertical Stripe |
| zone active | 344.232(H)×193.536(V) mm |
| contour sombre. | 363.8(H)×215.9(V) ×9.6(D) mm |
| zone de lunette | 350.4(H)×196.94(V) mm |
| traitement | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| luminosité | 400 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| direction de la vue | 6 o'clock |
| Temps de réponse | 10 (Typ.)(Tr+Td) |
| angle de vue | 85/85/50/80 (Typ.)(CR≥10) |
| mode de fonctionnement | TN, Normally White, Transmissive |
| couleur de soutien | 16.7M 62% NTSC |
| Source de lumière | WLED , 50K hours , With LED Driver |
| lester | 860g (Typ.) |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
