| Numéro d'article | G156HCE-L01 |
| Marque | Innolux |
| Taille | 15.6 |
| application | Industrial |
| Résolution | 1920×1080 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.2M |
| Rétroéclairage | WLED |
| Interface | |
| marque | Innolux |
| modèle | G156HCE-L01 |
| taille diagonale | 15.6 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1920(RGB)×1080 [FHD] 141PPI |
| configuration | RGB Vertical Stripe |
| zone active | 344.16(H)×193.59(V) mm |
| contour sombre. | 363.8(H)×215.98(V) ×9.6(D) mm |
| zone de lunette | 347.06(H)×196.49(V) mm |
| traitement | Antiglare, Hard coating (3H) |
| luminosité | 450 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 13/12 (Typ.)(Tr/Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10) |
| mode de fonctionnement | AAS, Normally Black, Transmissive |
| couleur de soutien | 16.2M 73% NTSC |
| Source de lumière | WLED , 50K hours , With LED Driver |
| lester | 1.06/1.10Kgs (Typ./Max.) |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C |
| B156HTN03.3 | AUO | 15.6 | 1920×1080 |
| G156HAN01.0 | AUO | 15.6 | 1920×1080 |
| G156HTD01.0 | AUO | 15.6 | 1920×1080 |
| G156HTN01.0 | AUO | 15.6 | 1920×1080 |
| G156HTN02.0 | AUO | 15.6 | 1920×1080 |
| G156HTN02.1 | AUO | 15.6 | 1920×1080 |
| G156XW01 V1 | AUO | 15.6 | 1366×768 |
| LTN156AT05-W01 | Samsung | 15.6 | 1366×768 |
| LTN156AT36-W01 | Samsung | 15.6 | 1366×768 |
| N156HGE-EA1 | Innolux | 15.6 | 1920×1080 |
