| Numéro d'article | G156HAB01.2 |
| Marque | AUO |
| Taille | 15.6 |
| application | Industrial |
| Résolution | 1920×1080 |
| Composition | a-Si TFT-LCD, Assemb |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.2M |
| Rétroéclairage | WLED |
| Interface | eDP |
| marque | AUO |
| modèle | G156HAB01.2 |
| taille diagonale | 15.6 inch |
| taper | a-Si TFT-LCD, Assembly |
| format pixel | 1920(RGB)×1080 [FHD] 141PPI |
| configuration | RGB Vertical Stripe |
| zone active | 344.16(H)×193.59(V) mm |
| contour sombre. | - |
| luminosité | - |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 25 (Typ.)(Tr+Td) |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10) |
| mode de fonctionnement | AHVA, Normally Black, Transmissive |
| couleur de soutien | 16.2M |
| Source de lumière | WLED , With LED Driver |
| lester | - |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | On-Cell Touch |
| type d'interface | eDP (2 Lanes) Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| AC156GA01 | Mitsubishi | 15.6 | 1366×768 |
| G156HAN01.0 | AUO | 15.6 | 1920×1080 |
| G156HTD01.0 | AUO | 15.6 | 1920×1080 |
| G156HTN01.0 | AUO | 15.6 | 1920×1080 |
| G156HTN02.0 | AUO | 15.6 | 1920×1080 |
| G156HTN02.1 | AUO | 15.6 | 1920×1080 |
| LP156WF1-TLB2 | LG Display | 15.6 | 1920×1080 |
| LP156WH4-TLN2 | LG Display | 15.6 | 1366×768 |
| N156BGE-E21 | Innolux | 15.6 | 1366×768 |
| NV156FHM-N43 | BOE | 15.6 | 1920×1080 |
