| Numéro d'article | G101STN01.7 |
| Marque | AUO |
| Taille | 10.1 |
| application | Industrial |
| Résolution | 1024×600 |
| Composition | a-Si TFT-LCD , LCM |
| Luminosité | |
| CR | 500:1 |
| Couleurs | 262K/16.7M |
| Rétroéclairage | WLED |
| Interface | |
| marque | AUO |
| taille diagonale | 10.1 inch |
| format pixel | 1024(RGB)×600 [WSVGA] 117PPI |
| zone active | 222.72(H)×125.28(V) mm |
| luminosité | - |
| direction de la vue | - |
| angle de vue | 70/70/60/60 (Typ.)(CR≥10) |
| couleur de soutien | 262K/16.7M 45% NTSC |
| lester | - |
| fréquence d'images | - |
| environnement | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| modèle | G101STN01.7 |
| taper | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| contour sombre. | - |
| Rapport de contraste | 500:1 (Typ.) (TM) |
| Temps de réponse | - |
| mode de fonctionnement | TN, Normally White, Transmissive |
| Source de lumière | WLED |
| conçu pour | Industrial |
| Ecran tactile | Without |
