| Numéro d'article | G101EAN02.1 |
| Marque | AUO |
| Taille | 10.1 |
| application | Industrial |
| Résolution | 1280×800 |
| Composition | a-Si TFT-LCD , LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | AUO |
| taille diagonale | 10.1 inch |
| format pixel | 1280(RGB)×800 [WXGA] 149PPI |
| zone active | 216.96(H)×135.6(V) mm |
| zone de lunette | - |
| luminosité | 400 cd/m² (Typ.) |
| direction de la vue | Symmetry |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10) |
| couleur de soutien | 16.7M 50% NTSC |
| lester | 195g (Max.) |
| fréquence d'images | 60Hz |
| type d'interface | LVDS (1 ch, 8-bit) , 40 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
| modèle | G101EAN02.1 |
| taper | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| contour sombre. | 227.72(H)×147.8(V) ×4.8(D) mm |
| traitement | Hard coating |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| Temps de réponse | 29 (Typ.)(Tr+Td) |
| mode de fonctionnement | AHVA, Normally Black, Transmissive |
| Source de lumière | WLED , 30K hours , With LED Driver |
| conçu pour | Industrial |
| Ecran tactile | Without |
