| Numéro d'article | EV156FHM-N10-5850 |
| Marque | BOE |
| Taille | 15.6 |
| application | Industrial |
| Résolution | 1920×1080 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | |
| marque | BOE |
| modèle | EV156FHM-N10-5850 |
| taille diagonale | 15.6 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1920(RGB)×1080 [FHD] 141PPI |
| configuration | RGB Vertical Stripe |
| zone active | 344.16(H)×193.59(V) mm |
| contour sombre. | 363.8(H)×215.9(V) ×9.9(D) mm |
| zone de lunette | 348.2(H)×197.6(V) mm |
| traitement | Antiglare |
| luminosité | 500 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 30 (Typ.)(Tr+Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10) |
| mode de fonctionnement | ADS, Normally Black, Transmissive |
| couleur de soutien | 16.7M 45% NTSC |
| Source de lumière | WLED [8S4P] , 50K hours , With LED Driver |
| lester | 850g (Max.) |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| Operating Temperature: 0 ~ 70 °C ; Storage Temperature: -20 ~ 80 °C |
| AC156GA01 | Mitsubishi | 15.6 | 1366×768 |
| B156RW01 V1 | AUO | 15.6 | 1600×900 |
| LP156WF1-TLF3 | LG Display | 15.6 | 1920×1080 |
| LP156WF4-SLC1 | LG Display | 15.6 | 1920×1080 |
| LP156WH2-TPB1 | LG Display | 15.6 | 1366×768 |
| LP156WH4-TPP1 | LG Display | 15.6 | 1366×768 |
| LQ156M3LW01 | SHARP | 15.6 | 1920×1080 |
| N156BGE-L11 | Innolux | 15.6 | 1366×768 |
| N156HGE-EAL Rev.C1 | Innolux | 15.6 | 1920×1080 |
| N156HGE-L11 | Innolux | 15.6 | 1920×1080 |
