| Numéro d'article | DV430FHM-NN1 |
| Marque | BOE |
| Taille | 43 |
| application | Digital Signage |
| Résolution | 1920×1080 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 1200:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | BOE |
| modèle | DV430FHM-NN1 |
| taille diagonale | 43 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1920(RGB)×1080 [FHD] 51PPI |
| configuration | RGB Vertical Stripe |
| zone active | 940.896(H)×529.254(V) mm |
| contour sombre. | 961.7(H)×550.1(V) ×27.7(D) mm |
| zone de lunette | - |
| traitement | Antiglare (Haze 1%), Hard coating (3H) |
| luminosité | 400 cd/m² (Typ.) |
| Rapport de contraste | 1200:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 8 (Typ.)(G to G) |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10) |
| mode de fonctionnement | ADS, Normally Black, Transmissive |
| couleur de soutien | 16.7M 72% NTSC |
| Source de lumière | WLED , 30K hours , With LED Driver |
| lester | 8.36Kgs (Typ.) |
| conçu pour | Digital Signage |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | LVDS (2 ch, 8-bit) , 51 pins Connector |
| source de courant | 12.0V (Typ.) |
| environnement | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
