| Numéro d'article | CLAA140WB01A |
| Marque | CPT |
| Taille | 14.0 |
| application | NBPC |
| Résolution | 1366×768 |
| Composition | LCM |
| Luminosité | 200 |
| CR | 600:1 |
| Couleurs | 262K |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque de panneau | CPT |
| modèle de panneau | CLAA140WB01A 5 Compatible model |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 14.0 inch |
| résolution | 1366(RGB)×768 , WXGA |
| mode d'affichage | TN, Normally White, Transmissive |
| zone active | 309.399×173.952 mm |
| contour | 320.4×205.1×3.6 mm |
| style de forme | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| surface | Glare (Haze 0%) |
| luminosité | 200 cd/m² (Typ.) |
| Rapport de contraste | 600:1 (Typ.) |
| couleurs d'affichage | 262K (6-bit), CIE193145% |
| Temps de réponse | 3/5 (Typ.)(Tr/Td) |
| angle de vue | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | WLEDEmbedded (LED Driver) |
| interface de signaux | LVDS (1 ch, 6-bit), 40 pins |
| tension d'entrée | 3.3V (Typ.) |
| CLAA140UA01 CN | CPT | 14.0 | 1600×900 |
| CLAA140WA01 | CPT | 14.0 | 1280×768 |
| CLAA140WB01A | CPT | 14.0 | 1366×768 |
| CLAA140WB11A | CPT | 14.0 | 1366×768 |
| CLAA141WB05A | CPT | 14.1 | 1280×800 |
| CLAA141WB11 | CPT | 14.1 | 1280×800 |
| LP140WD1-TLM1 | LG Display | 14.0 | 1600×900 |
| N140B6-D11 | Innolux | 14.0 | 1366×768 |
| N140BGE-E43 | Innolux | 14.0 | 1366×768 |
| N140BGN-E42 | Innolux | 14.0 | 1366×768 |
| B133HAN02.5 | AUO | 13.3 | 1920×1080 |
| B156HTB01.0 | AUO | 15.6 | 1920×1080 |
| HSD173PUW1-A | HannStar | 17.3 | 1920×1080 |
| LP140WD2-TPB1 | LG Display | 14.0 | 1600×900 |
| LP140WH2-TLE2 | LG Display | 14.0 | 1366×768 |
| LP171WP4-TLP1 | LG Display | 17.1 | 1440×900 |
| LQ10W03A | SHARP | 10.4 | 1024×600 |
| LTM12C278F | TOSHIBA | 12.1 | 800×600 |
| N133HSE-EB3 | Innolux | 13.3 | 1920×1080 |
| N154C6-L04 | Innolux | 15.4 | 1440×900 |
