| Numéro d'article | CLAA123PA02CW |
| Marque | CPT |
| Taille | 12.3 |
| application | Industrial Outdoor H |
| Résolution | 1440×540 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 700:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | CPT |
| modèle | CLAA123PA02CW |
| taille diagonale | 12.3 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1440(RGB)×540 125PPI |
| configuration | RGB Vertical Stripe |
| zone active | 291.6(H)×109.35(V) mm |
| contour sombre. | 312.9(H)×132.2(V) ×19.2(D) mm |
| zone de lunette | 294.8(H)×112.4(V) mm |
| traitement | Antiglare (Haze 25%) |
| luminosité | 800 cd/m² (Typ.) |
| Rapport de contraste | 700:1 (Typ.) (TM) |
| direction de la vue | 6 o'clock |
| Temps de réponse | 25 (Typ.)(Tr+Td) |
| angle de vue | 60/60/50/60 (Typ.)(CR≥10) |
| mode de fonctionnement | TN, Normally White, Transmissive |
| couleur de soutien | 16.7M 70% NTSC |
| Source de lumière | WLED [8S3P] , 30K hours , W/O Driver |
| lester | 510g (Typ.) |
| conçu pour | Industrial Outdoor High Brightness Automotive Display |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
