| Numéro d'article | CLAA101WK07 XN |
| Marque | CPT |
| Taille | 10.1 |
| application | Automotive Display |
| Résolution | 1280×720 |
| Composition | a-Si TFT-LCD , LCM |
| Luminosité | |
| CR | 900:1 |
| Couleurs | 262K/16.7M |
| Rétroéclairage | WLED |
| Interface | |
| marque | CPT |
| taille diagonale | 10.1 inch |
| format pixel | 1280(RGB)×720 [WXGA] 144PPI |
| zone active | 224.64(H)×126.36(V) mm |
| zone de lunette | 227.64(H)×129.36(V) mm |
| luminosité | 600 cd/m² (Typ.) |
| direction de la vue | Symmetry |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10) |
| couleur de soutien | 262K/16.7M 70% NTSC |
| lester | 430g (Typ.) |
| fréquence d'images | 60Hz |
| modèle | CLAA101WK07 XN |
| taper | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| contour sombre. | 238.8(H)×148.05(V) ×8.7(D) mm |
| traitement | Antiglare (Haze 25%), Hard coating (3H) |
| Rapport de contraste | 900:1 (Typ.) (TM) |
| Temps de réponse | 25 (Typ.)(Tr+Td) |
| mode de fonctionnement | HFFS, Normally Black, Transmissive |
| Source de lumière | WLED [6S5P] , 30K hours , W/O Driver |
| conçu pour | Automotive Display |
| Ecran tactile | Without |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| CLAA101NA0ACN | CPT | 10.1 | 1024×576 |
| CLAA101NC01CW | CPT | 10.1 | 1024×600 |
| CLAA101NC05 | CPT | 10.1 | 1024×600 |
| CLAA101ND06CW | CPT | 10.1 | 1024×600 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| CLAA101WH13LE | CPT | 10.1 | 1280×800 |
| CLAA101WJ02 | CPT | 10.1 | 1366×768 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
