| Numéro d'article | AX080E002B |
| Marque | KOE |
| Taille | 31.5 |
| application | LCTV |
| Résolution | 1366×768 |
| Composition | LCM |
| Luminosité | 500 |
| CR | 950:1 |
| Couleurs | 16.7M |
| Rétroéclairage | EEFL |
| Interface | LVDS |
| marque de panneau | IPS Alpha |
| modèle de panneau | AX080E002B |
| type de panneau | a-Si TFT-LCD , LCM |
| taille du panneau | 31.5 inch |
| résolution | 1366(RGB)×768 , WXGA |
| mode d'affichage | IPS-Pro, Normally Black, Transmissive |
| zone active | 697.685×392.256 mm |
| contour | 760×450 mm |
| surface | Antiglare |
| luminosité | 500 cd/m² (Typ.) |
| Rapport de contraste | 950:1 (Typ.) |
| couleurs d'affichage | 16.7M (8-bit) |
| Temps de réponse | 8/6 (Typ.)(Tr/Td); 17 (Typ.)(MPRT) |
| angle de vue | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| fréquence | 60Hz |
| type de lampe | 16 pcsEEFLEmbedded (Inverter) |
| interface de signaux | LVDS (1 ch, 8-bit), 41 pins |
| tension d'entrée | 12.0V (Typ.) |
