| Numéro d'article | AM-800480LTMQW-WAH |
| Marque | AMPIRE |
| Taille | 5.0 |
| application | Industrial |
| Résolution | 800×480 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 500:1 |
| Couleurs | 262K |
| Rétroéclairage | WLED |
| Interface | CPU |
| marque | AMPIRE |
| modèle | AM-800480LTMQW-WAH |
| taille diagonale | 5.0 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 800(RGB)×480 [WVGA] 188PPI |
| configuration | RGB Vertical Stripe |
| zone active | 108(H)×64.8(V) mm |
| contour sombre. | 118.5(H)×77.1(V) ×6.37(D) mm |
| zone de lunette | 110.6(H)×67.4(V) mm |
| traitement | - |
| luminosité | 470 cd/m² (Typ.) |
| Rapport de contraste | 500:1 (Typ.) (TM) |
| direction de la vue | - |
| Temps de réponse | 15/35 (Typ.)(Tr/Td) |
| angle de vue | 70/70/70/50 (Typ.)(CR≥10) |
| mode de fonctionnement | TN, Normally White, Transmissive |
| couleur de soutien | 262K 52% NTSC |
| Source de lumière | WLED [3S6P] , With LED Driver |
| lester | TBD |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | CPU , 40 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
