| Numéro d'article | AM-800480D1TMQW-00H |
| Marque | AMPIRE |
| Taille | 8.0 |
| application | Industrial Automotiv |
| Résolution | 800×480 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 500:1 |
| Couleurs | 262K/16.7M |
| Rétroéclairage | WLED |
| Interface | |
| marque | AMPIRE |
| modèle | AM-800480D1TMQW-00H |
| taille diagonale | 8.0 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 800(RGB)×480 [WVGA] 116PPI |
| configuration | RGB Vertical Stripe |
| zone active | 176.64(H)×99.36(V) mm |
| contour sombre. | 192.8(H)×116.9(V) ×6.7(D) mm |
| zone de lunette | 180.1(H)×103.4(V) mm |
| traitement | Antiglare |
| luminosité | 450 cd/m² (Typ.) |
| Rapport de contraste | 500:1 (Typ.) (TM) |
| direction de la vue | - |
| Temps de réponse | 10/15 (Typ.)(Tr/Td) |
| angle de vue | 70/70/50/70 (Typ.)(CR≥10) |
| mode de fonctionnement | TN, Normally White, Transmissive |
| couleur de soutien | 262K/16.7M |
| Source de lumière | WLED , 20K hours , W/O Driver |
| lester | 251g (Typ.) |
| conçu pour | Industrial Automotive Display |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
