| Numéro d'article | AM-19201200CTZQW-02 |
| Marque | AMPIRE |
| Taille | 10.1 |
| application | Industrial Outdoor H |
| Résolution | 1920×1200 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | AMPIRE |
| modèle | AM-19201200CTZQW-02 |
| taille diagonale | 10.1 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1920(RGB)×1200 [WUXGA] 225PPI |
| configuration | RGB Vertical Stripe |
| zone active | 216.576(H)×135.36(V) mm |
| contour sombre. | 244.8(H)×155.3(V) ×7.07(D) mm |
| luminosité | 1000 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 25 (Typ.)(Tr+Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10) |
| mode de fonctionnement | AHVA, Normally Black, Transmissive |
| couleur de soutien | 16.7M 49% NTSC |
| Source de lumière | WLED , 50K hours , With LED Driver |
| lester | - |
| conçu pour | Industrial Outdoor High Brightness |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | LVDS (2 ch, 8-bit) , 45 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -20 ~ 65 °C |
