| Numéro d'article | AM-1280800P4TZQW-T00H |
| Marque | AMPIRE |
| Taille | 7.0 |
| application | Industrial Outdoor H |
| Résolution | 1280×800 |
| Composition | a-Si TFT-LCD , LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | |
| marque | AMPIRE |
| taille diagonale | 7.0 inch |
| format pixel | 1280(RGB)×800 [WXGA] 217PPI |
| zone active | 149.76(H)×93.6(V) mm |
| zone de lunette | 152.76(H)×96.6(V) mm |
| luminosité | 1275 cd/m² (Typ.) |
| direction de la vue | Symmetry |
| angle de vue | 80/80/80/80 (Typ.)(CR≥10) |
| couleur de soutien | 16.7M 50% NTSC |
| lester | - |
| fréquence d'images | 60Hz |
| modèle | AM-1280800P4TZQW-T00H |
| taper | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| contour sombre. | 162.3(H)×107.9(V) ×11.76(D) mm |
| traitement | - |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| Temps de réponse | 35 (Typ.)(Tr+Td) |
| mode de fonctionnement | SFT, Normally Black, Transmissive |
| Source de lumière | WLED [5S4P] , 50K hours , With LED Driver |
| conçu pour | Industrial Outdoor High Brightness |
| Ecran tactile | PCAP |
| A070FW03 V8 | AUO | 7.0 | 480×234 |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-00H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| BP070WS1-500 | BOE | 7.0 | 1024×600 |
| C070VW01 V0 | AUO | 7.0 | 800×480 |
| LA070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LT070ME05000 | JDI | 7.0 | 1200×1920 |
| N070ICG-LD3 | Innolux | 7.0 | 1280×800 |
| TFD70W11-F1 | TOSHIBA | 7.0 | 480×234 |
