| Numéro d'article | AM-1280800J4TZQW-T00 |
| Marque | AMPIRE |
| Taille | 10.1 |
| application | Industrial |
| Résolution | 1280×800 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | AMPIRE |
| modèle | AM-1280800J4TZQW-T00 |
| taille diagonale | 10.1 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1280(RGB)×800 [WXGA] 149PPI |
| configuration | RGB Vertical Stripe |
| zone active | 216.96(H)×135.6(V) mm |
| contour sombre. | 231(H)×150(V) ×8.8(D) mm |
| luminosité | 300 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 10/15 (Typ.)(Tr/Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10) |
| mode de fonctionnement | Normally Black, Transmissive |
| couleur de soutien | 16.7M |
| Source de lumière | WLED [3S11P] , 15K hours , With LED Driver |
| lester | TBD |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | PCAP |
| type d'interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-00H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| B101XTN01.1 | AUO | 10.1 | 1366×768 |
| BP101WX1-200 | BOE | 10.1 | 1280×800 |
| HSD100IFW4-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW4-A00 | HannStar | 10.1 | 1024×600 |
| LP101WH1-TLB2 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLAB | LG Display | 10.1 | 1366×768 |
| TV101QUM-N00 | BOE | 10.1 | 3840×2160 |
