| Numéro d'article | AM-1024768V1TZQW-A0H |
| Marque | AMPIRE |
| Taille | 8.4 |
| application | Industrial |
| Résolution | 1024×768 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 1000:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | AMPIRE |
| modèle | AM-1024768V1TZQW-A0H |
| taille diagonale | 8.4 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1024(RGB)×768 [XGA] 152PPI |
| configuration | RGB Vertical Stripe |
| zone active | 170.8(H)×128.1(V) mm |
| contour sombre. | 203(H)×145.5(V) ×8(D) mm |
| zone de lunette | 174.15(H)×131.2(V) mm |
| traitement | - |
| luminosité | 1000 cd/m² (Typ.) |
| Rapport de contraste | 1000:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 30 (Typ.)(Tr+Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10) |
| mode de fonctionnement | IPS, Normally Black, Transmissive |
| couleur de soutien | 16.7M |
| Source de lumière | WLED [6S6P] , 50K hours , With LED Driver |
| lester | - |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
