| Numéro d'article | AM-1024768TTMQW-T00H |
| Marque | AMPIRE |
| Taille | 10.4 |
| application | Industrial |
| Résolution | 1024×768 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 900:1 |
| Couleurs | 262K/16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | AMPIRE |
| modèle | AM-1024768TTMQW-T00H |
| taille diagonale | 10.4 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1024(RGB)×768 [XGA] 123PPI |
| configuration | RGB Vertical Stripe |
| zone active | 211.2(H)×158.4(V) mm |
| contour sombre. | 236(H)×176.9(V) ×7.9(D) mm |
| zone de lunette | 214.8(H)×162.0(V) mm |
| traitement | Antiglare |
| luminosité | 280 cd/m² (Typ.) |
| Rapport de contraste | 900:1 (Typ.) (TM) |
| direction de la vue | 6 o'clock |
| Temps de réponse | 16 (Typ.)(Tr+Td) |
| angle de vue | 75/75/75/75 (Typ.)(CR≥10) |
| mode de fonctionnement | TN, Normally White, Transmissive |
| couleur de soutien | 262K/16.7M |
| Source de lumière | WLED [4 strings] , 30K hours , With LED Driver |
| lester | 290g (Max.) |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | 4-wire Resistive Touch |
| type d'interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| G104SN05 V0 | AUO | 10.4 | 800×600 |
| LM-CJ53-22NAK | SANYO | 10.4 | 640×480 |
| LQ10D341 | SHARP | 10.4 | 640×480 |
| LQ10D368 | SHARP | 10.4 | 640×480 |
| LQ10D41 | SHARP | 10.4 | 640×480 |
| LTM104V3-100 | Samsung | 10.4 | 640×480 |
| PD104SL7 | E Ink | 10.4 | 800×600 |
