| Numéro d'article | AM-1024768R3TNQW-T00H |
| Marque | AMPIRE |
| Taille | 12.1 |
| application | Industrial |
| Résolution | 1024×768 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 262K/16.7M |
| Rétroéclairage | WLED |
| Interface | |
| marque | AMPIRE |
| modèle | AM-1024768R3TNQW-T00H |
| taille diagonale | 12.1 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1024(RGB)×768 [XGA] 105PPI |
| configuration | RGB Vertical Stripe |
| zone active | 245.76(H)×184.32(V) mm |
| contour sombre. | 279(H)×209(V) ×11.2(D) mm |
| luminosité | 300 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| direction de la vue | - |
| Temps de réponse | 16 (Typ.)(Tr+Td) |
| angle de vue | 80/80/80/80 (Typ.)(CR≥10) |
| mode de fonctionnement | TN, Normally White, Transmissive |
| couleur de soutien | 262K/16.7M |
| Source de lumière | WLED , 30K hours , With LED Driver |
| lester | - |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | PCAP |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
